MS Spectrum

What do you want to do?

• Set number of panels to be shown

• Overlay MS Spectra

• Hide gridlines

• Extract MS spectrum via right-click on a peak

• Extract MS spectrum with the spectrum extraction tool

• Extract an MS background spectrum

• Extract multiple MS spectra in one step

• Automatically extract MS spectra on reprocessing

• Change parameters for MS background spectra

• Add new compound to the processing method

• Adjust MS spectrum threshold

• Configure MS spectral smoothing

• Export MS Spectrum

MS Spectrum

This window shows the MS spectrum acquired at a specific retention time or averaged over a time range. The spectrum is in centroid or profile mode, depending on the settings in the acquisition method. The spectrum may be background subtracted. Spectrum type (peak apex or average) and background subtraction depend on the settings in the processing method. The selected spectrum is associated with the selected peak (for example, in the Chromatograms window).



MS Spectrum, centroid mode
